Details
| Diagram | Fig. 26 — REAR BRAKE · ref 56 |
| Subsystem | brakes |
| Listed in parts books | 1976–1978, 1980, 1983 |
Spindle, rear brake pedal
Spindle for the rear brake pedal, the pivot shaft the pedal swings on.
PN · 83-7046
This is the spindle for the rear brake pedal, part number 83-7046. It's the shaft the rear brake pedal pivots on, mounted at the frame where the pedal meets the bike. Our catalog record for this one comes from a single 1979 listing under the REAR BRAKE figure, so what we can tell you about fitment is limited to that.
$41.49
Pin your bike to check this part fits.
Sorry if we got something wrong here. If you think this information isn't correct, .
