| Diagram | Fig. 14 — FRAME · ref 21 |
| Subsystem | engine bottom |
| Listed in parts books | 1979–1980, 1983, 1985 |
PIPE,OIL RETURN (9/32 x 16.5)
Oil return pipe (9/32 x 16.5), PN 71-7058, from the motor unit fitting and footrest area of the frame.
This is the oil return pipe listed in the catalog as PN 71-7058, a small line that carries oil back from the top of the motor into the return circuit. It shows up in the parts book under the MOTOR UNIT FITTING AND FOOTRESTS figure, which places it down in the area where the engine unit mounts into the frame and the footrest hardware lives.
Read more
The listing gives it as a 9/32 x 16.5 pipe, so if you're matching up an old one that's kinked, cracked, or just missing off the bike, check those dimensions against what you're holding before you order.
We only see this part turn up in our 1980 catalog listings, so we can't speak to earlier or later years. If your parts book shows something close but not identical, give us a call and we'll sort out whether this is the right one.
