| Diagram | Fig. 33 — MAGNETO WITH MANUAL CONTROL · ref 21 |
| Subsystem | electrical |
| Listed in parts books | 1960–1962 |
END PLATE K2F W MAN.ADVANCE
End plate for a Lucas K2F magneto fitted with manual advance control.
This is the end plate off a Lucas K2F magneto fitted with manual advance control. The K2F is a magneto, part of the ignition side of the bike rather than anything to do with fuel or charging, and this plate closes off the end of the unit where the manual advance mechanism lives. Our catalog record ties it to the magneto-with-manual-control figure, which is where you'd expect an end plate like this to show up.
Read more
If you're working on a K2F magneto with the lever-type manual advance rather than the automatic type, this is the plate that covers that end. It's a small but important piece of the housing — it keeps the internals sealed up and gives the advance mechanism something to pivot against.
We don't have a lot more detail on this one beyond what's in the parts book. If you're not sure whether your magneto is the manual-advance K2F or a different variant, give us a call before you order so we can confirm you're getting the right end plate.
