| Diagram | Fig. 24 — CARBURETTER · ref 26 |
| Subsystem | fuel |
| Listed in parts books | 1969 |
Pilot jet, size 25 c.c.
Amal carburetor pilot jet, size 25 c.c., for idle and low-speed fuel metering.
This is a pilot jet for an Amal carburetor, listed in the parts book as size 25 c.c. It shows up in the CARBURETTER figure, which tells us where it lives in the fuel system but not much beyond that. The pilot jet controls fuel delivery at idle and low throttle openings, working alongside the main jet and needle to shape how the carb responds off the closed throttle position.
Read more
Our catalog record for this one is thin. It appears twice across the catalog with a year range centered on 1969, but we don't have details on which specific model or carb body it was paired with. If you're chasing a pilot jet for a particular bike, bring in the carb or the number off the body so we can confirm before you buy.
The part also shows up under the alternate number 124/026, which is worth having on hand if your parts book or an old invoice lists it that way instead.
We've never carried this one. Tell us what you're after and we'll go looking — you'll get a price and photos before you commit to anything.
Sorry if we got something wrong here. If you think this information isn't correct, .
