| Also known as | 15-518 |
| Diagram | Fig. 21 — MUDGUARDS · ref 6 |
| Subsystem | bodywork |
| Listed in parts books | 1969–1970 |
BSA Bolt, stay to bracket (5/16" British Standard Cycle × 1-1/32")
Mudguard stay-to-bracket bolt, 5/16 in. BSC thread by 1-1/32 in. long.
This is a mudguard stay bolt, 5/16 inch British Standard Cycle thread by 1-1/32 inch long, used to hold the mudguard stay to its mounting bracket. It shows up in the mudguard section of the parts books, so it's doing bracket duty on the fender stays rather than anything structural to the frame.
Read more
The catalog listing for this one covers 1969–1970, so it's a fastener specific to that stretch of the range rather than a generic hardware-store bolt in length and thread. If you're replacing mudguard stay hardware and the old bolt is rusted or the head's chewed up, this is the one to match up against your parts book listing before ordering.
It's also listed under the older number 15-518, same physical part, just the earlier catalog form of the number.
We've never carried this one. Tell us what you're after and we'll go looking — you'll get a price and photos before you commit to anything.
