| Diagram | Fig. 17 — HANDRAIL, SUPPORT RAIL, FOOTRESTS · ref 16 |
| Subsystem | frame |
| Listed in parts books | 1970 |
Norton Washer, footrest stud
A washer for a footrest stud, part number 02-1945.
This is a washer that fits on a footrest stud, part number 02-1945. It shows up in the catalog under the footrest and support rail figures, so it lives at the mounting point where a rider or passenger peg attaches to the frame or a bracket.
Read more
Our catalog record for this one is brief - it appears twice, both times tied to the footrest hardware, with the year range on file limited to 1970. Given that, check it against the stud and bracket you're working with before ordering.
If you're rebuilding footrest mounts and need a washer to go with the stud, this is a candidate, but call the shop and we'll confirm fitment before you order.
